ESP32 30 Pin Development Board with Wi-Fi and Bluetooth

ESP32 30 Pin Wi-Fi and Bluetooth Development Board

Build connected prototypes with an ESP32-WROOM-32 based 30 pin development board. The module provides a dual-core Xtensa LX6 processor, 2.4 GHz Wi-Fi, Bluetooth 4.2 Classic and LE, and 4 MB SPI flash. The board adds a Micro USB programming connection and a compact header layout.

Key features

• ESP32-WROOM-32 module with dual-core CPU up to 240 MHz and 4 MB SPI flash
• 2.4 GHz Wi-Fi 802.11 b/g/n and Bluetooth 4.2 Classic/LE
• 30 header pins; usable GPIO count and peripheral routing depend on the board
• Micro USB programming connection with a USB-to-UART bridge; supplier board revisions may use CP2102 or CH340
• Arduino IDE, ESP-IDF and MicroPython development support

Applications

Wireless sensors, automation controllers, data logging, robotics and embedded learning projects.

Package contents

1 × ESP32 30 pin development board.

Power note: The module uses a regulated 3.0–3.6 V supply. Use the board's supported USB/input connection; GPIO pins are not 5 V tolerant.

• Board Type
  ESP32 30 pin development board
• Module
  ESP32-WROOM-32
• CPU
  Dual-core Xtensa LX6, up to 240 MHz
• Flash
  4 MB SPI flash (module)
• Wi-Fi
  2.4 GHz IEEE 802.11 b/g/n
• Bluetooth
  Bluetooth 4.2 Classic and LE
• Header Pins
  30 total; not all pins are GPIO
• USB Connector
  Micro USB
• USB-to-UART
  CP2102 or CH340; supplied bridge may vary
• Module Supply
  3.0–3.6 V; board powered through USB
• Package Contents
  1 × ESP32 30 pin development board
