ESP32-S3-WROOM-N16R8 Dual C-Type USB Development Board WiFi + Bluetooth Module

ESP32-S3-WROOM-1-N16R8 Dual USB-C Development Board

Build Wi-Fi and Bluetooth Low Energy projects with the ESP32-S3-WROOM-1-N16R8 module. The board combines a dual-core Xtensa LX7 processor running up to 240 MHz with 16 MB flash and 8 MB Octal SPI PSRAM for connected and memory-intensive embedded applications.

Key features

• ESP32-S3-WROOM-1-N16R8 module with 2.4 GHz Wi-Fi and Bluetooth LE
• 16 MB Quad SPI flash and 8 MB Octal SPI PSRAM
• Two USB Type-C connectors for board power and programming/data; available USB functions depend on board routing and firmware
• GPIO and peripherals for sensors, displays, robotics and other embedded projects; usable pin count depends on board routing
• Develop with ESP-IDF, Arduino IDE or MicroPython

Applications

Suitable for IoT prototypes, wireless sensor nodes, automation, robotics and USB-enabled embedded development.

Package contents

1 × ESP32-S3-WROOM-1-N16R8 dual USB-C development board.

Power note: The 3.0–3.6 V specification refers to the module supply. Power the complete board through its supported USB-C or board input connection.

• Module
  ESP32-S3-WROOM-1-N16R8
• SoC
  ESP32-S3
• CPU
  Dual-core Xtensa LX7, up to 240 MHz
• Flash Memory
  16 MB
• PSRAM
  8 MB Octal SPI PSRAM
• Wireless
  2.4 GHz Wi-Fi 802.11 b/g/n and Bluetooth LE
• USB Ports
  2 × USB Type-C
• USB Functions
  Power, programming/data; native USB OTG/JTAG support depends on board routing
• GPIO
  Up to 36 exposed GPIO; board routing may limit usable pins
• ADC
  12-bit ADC (ESP32-S3 capability)
• Module Supply
  3.0–3.6 V; power the board through its supported USB-C/input interface
• Development Platforms
  Arduino IDE, ESP-IDF and MicroPython
• Package Contents
  1 × ESP32-S3-WROOM-1-N16R8 dual USB-C development board
