VL53L1X Time-of-Flight (ToF) Distance Sensor Module
- Based on the STMicroelectronics VL53L1X Time-of-Flight laser ranging sensor
- Measures distances up to 4 meters with millimeter-level accuracy
- Features programmable short, medium, and long-distance modes for versatile applications
- Supports I²C communication for seamless integration with Arduino, Raspberry Pi, ESP32, and other microcontrollers
- Offers ambient light immunity for reliable indoor and outdoor measurements
- Compact, low-power design ideal for robotics, drones, automation, and IoT projects
Product Details
VL53L1X Time-of-Flight (ToF) Distance Sensor Module
The VL53L1X Time-of-Flight (ToF) Distance Sensor Module is a high-performance laser-ranging sensor based on STMicroelectronics' advanced VL53L1X sensor IC. Utilizing Time-of-Flight technology, the module accurately measures distance by calculating the time taken for emitted infrared laser pulses to reflect back from an object.
With an extended measurement range of up to 4 meters, programmable distance modes, and customizable region-of-interest settings, the VL53L1X delivers highly accurate and reliable distance measurements. Its resistance to ambient light interference makes it suitable for indoor and outdoor applications, while the I²C interface ensures easy integration with Arduino, Raspberry Pi, ESP32, STM32, and other development platforms.
🔧 Features
- Based on the STMicroelectronics VL53L1X ToF sensor IC
- Extended measurement range of up to 4 meters
- Programmable ROI (Region of Interest) for optimized sensing
- Supports short, medium, and long-distance measurement modes
- I²C communication interface for simple integration
- High immunity to ambient light interference
- Low power consumption suitable for battery-powered applications
- Compact PCB design with mounting holes
- Fast and accurate millimeter-level distance measurements
📋 Specifications
- Model: VL53L1X ToF Distance Sensor Module
- Sensor IC: VL53L1X (STMicroelectronics)
- Operating Voltage: 2.6V – 5V DC
- Logic Compatibility: 3.3V / 5V
- Communication Interface: I²C (SCL, SDA)
- Measurement Range: 40mm – 4000mm
- Field of View: Approximately 27° (Programmable)
- Pins: VIN, GND, SCL, SDA, GPIO1, XSHUT
- Dimensions: Approx. 20 × 10 mm
- Weight: Approx. 2g
📦 Package Includes
- 1 × VL53L1X Time-of-Flight (ToF) Distance Sensor Module
